Lucid arena pro

  • Areas of application

    Demanding industrial environments, sports facilities, food industry, cold stores, production halls and warehouses

  • Protection degree

    IP 66 in accordance with DIN EN 60529

  • Beam angle

    Available with 60° or 120° beam angle

  • Control system

    Can be automated via DALI and 0-10 volt function

  • Photobiological safety

    High-quality LEDs ensure that the retina remains undamaged even during long periods of work

Germany's first certified indoor LED light

The Lucid arena pro from LIGHTS illuminates your halls with ideal, homogeneous LED light.

It is the first VDE-certified LED high bay luminaire on the German market and has been impressing well-known customers for over 15 years thanks to its dynamic further development and its presence in our product portfolio. The first model of the Lucid arena pro is exhibited in the German Museum in Munich and is considered a milestone in LED technology.

To this day, every single spotlight is assembled and tested in Backnang and clearly stands out from the market in terms of functionality and quality. With 160 LEDs of the latest generation, optimized weight, the use of high-performance optics and an individually adjustable long-life power supply unit, energy savings of up to 80% are achieved with the best quality of light. It is available with 60° and 120° beam patterns. The swivel mounting bracket ensures flexibility.

The LED high bay luminaire is also optionally available with DALI or 0-10 volt function, allowing you to adjust your high bay lighting to the ideal brightness and save even more energy. You can also rely on the Lucid Arena pro in emergency situations, as it can also be used as emergency power lighting. Whether narrow or wide beam, daylight white or normal white, the Lucid Arena pro is available in many versions to illuminate your hall in the best possible way to suit your needs.

The housing of the LED high-bay luminaire is made of powder-coated die-cast aluminum, guaranteeing particularly long stability, corrosion resistance and service life. The power supply unit is individually adjustable, thermally decoupled from the luminaire heat sink and is easy to replace. The Lucid arena can be optionally extended with accessories such as dust covers, anti-twist devices, cable extensions, corner brackets and much more.

Up to 0 years
Manufacturer's guarantee
Up to 0 years
Spare parts guarantee

Variants

Lucid arena pro 120

Art. No. Beam angle Color temperature* CRI Luminous flux/output Protection degree Ambient temperature
38631
120°
5.000 K | daylight white
Ra > 85
15.700 lm – 23.550 / 100 – 150 W
IP 66
-30°C to +50°C
38632
120°
4.000 K | normal white
Ra > 85
16.000 lm - 24.000 lm / 100 - 150 W
IP 66
-30°C to +50°C
78631
120°
5.000 K | daylight white
Ra > 85
15.700 lm – 23.550 / 100 – 150 W
IP 66
-30°C to +50°C
78632
120°
4.000 K | normal white
Ra > 85
16.000 lm – 24.000 / 100 – 150 W
IP 66
-30°C to +50°C
Art. No. Beam angle Color temperature* CRI Luminous flux/output Protection degree Ambient temperature
38631
120°
5.000 K | daylight white
Ra > 85
15.700 lm – 23.550 / 100 – 150 W
IP 66
-30°C to +50°C
38632
120°
4.000 K | normal white
Ra > 85
16.000 lm - 24.000 lm / 100 - 150 W
IP 66
-30°C to +50°C
78631
120°
5.000 K | daylight white
Ra > 85
15.700 lm – 23.550 / 100 – 150 W
IP 66
-30°C to +50°C
78632
120°
4.000 K | normal white
Ra > 85
16.000 lm – 24.000 / 100 – 150 W
IP 66
-30°C to +50°C

Lucid arena pro 60

Art. No. Beam angle Color temperature* CRI Luminous flux/output Protection degree Ambient temperature
38636
60°
5.000 K | daylight white
Ra > 85
15.800 lm – 23.700 / 100 – 150 W
IP 66
-30°C to +50°C
38637
60°
4.000 K | normal white
Ra > 85
15.200 lm – 22.800 / 100 – 150 W
IP 66
-30°C to +50°C
78636
60°
5.000 K | daylight white
Ra > 85
15.800 lm – 23.700 / 100 – 150 W
IP 66
-30°C to +50°C
78637
60°
4.000 K | normal white
Ra > 85
15.200 lm – 22.800 / 100 – 150 W
IP 66
-30°C to +50°C
Art. No. Beam angle Color temperature* CRI Luminous flux/output Protection degree Ambient temperature
38636
60°
5.000 K | daylight white
Ra > 85
15.800 lm – 23.700 / 100 – 150 W
IP 66
-30°C to +50°C
38637
60°
4.000 K | normal white
Ra > 85
15.200 lm – 22.800 / 100 – 150 W
IP 66
-30°C to +50°C
78636
60°
5.000 K | daylight white
Ra > 85
15.800 lm – 23.700 / 100 – 150 W
IP 66
-30°C to +50°C
78637
60°
4.000 K | normal white
Ra > 85
15.200 lm – 22.800 / 100 – 150 W
IP 66
-30°C to +50°C

Special solutions for special requirements are available on request.

* also available in 3,000 K and 6,500 K on request

Feel free to contact us!

Our sales team will advise you without any obligations in order to realize the ideal lighting conditions for you.

You can reach us on +49 (0)7191 32 30 20 or via the contact form below.
